Contents
WHAT IS WHAT .................................................... 3
WARNINGS AND SAFETY INSTRUCTIONS ........ 4
SPECIFICATIONS ................................................. 6
ASSEMBLY PROCEDURES ................................. 8
OPERATING PROCEDURES .............................. 10
MAINTENANCE .................................................. 12
TROUBLESHOOTING......................................... 16
MEANINGS OF SYMBOLS
NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand
their meaning before use.
It is important that you read, fully
understand and observe the
following safety precautions and
warnings. Careless or improper
use of the unit may cause serious
or fatal injury.
Choke - Run position (Open)
Choke - Start position
(Closed)
Read, understand and follow all
warnings and instructions in this
manual and on the unit.
Ignition stop
Always wear eye, head and ear
protectors when using this unit.
Fuel and oil mixture
Keep all children, bystanders
and helpers 15 m away from
the unit. If anyone approaches
you, stop the engine and cutting
attachment immediately.
4
Guaranteed Sound power
level
Be careful of thrown objects.
Hot surface – Contact with
hot surface can cause serious
burns.
min
-1
Shows maximum shaft speed. Do
not use the cutting attachment
whose max rpm is below the
shaft rpm.
Indicate handle location. Do
not attach handle above this
point.
Gloves should be worn
when necessary, e.g., when
assembling cutting equipment.
Indicates cutting attachment
guard location for a trimmer
head or semi-auto cutting
head.
Use anti-slip and sturdy footwear.
Before using your machine
• Read the manual carefully.
• Check that the cutting equipment is correctly assembled and adjusted.
• Start the unit and check the carburetor adjustment. See “MAINTENANCE”.
