English
3
MEANINGS OF SYMBOLS
NOTE:
Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning before
use.
It is important that you read, fully understand
and observe the following safety precautions
and warnings. Careless or improper use of
the unit may cause serious or fatal injury.
Emergency stop
Read, understand and follow all warnings
and instructions in this manual and on the
unit.
Fuel and oil mixture
Always wear eye, head and ear protectors
when using this unit.
Chain oil fi ll
Warning, kickback danger. Be careful of
possible sudden and accidental upward
and/or backward motion of the guide bar.
Carburetor adjustment - Idle speed
One-handed usage not permitted. While
cutting, hold saw fi rmly with both hands with
thumb fi rmly locked around front handle.
Carburetor adjustment - Low speed mixture
The saw is specially designed for tree
service and therefore shall be used by
trained operators only, in off -ground work
in trees.
Carburetor adjustment - High speed mixture
Chain brake Hot surface
Choke - Run position (Open) Priming pump
Choke - Choked position (Closed)
35°
Computed kickback angle (CKA) with
actuated chain brake
On/Start
50°
Computed kickback angle (CKA) without
a chain brake
Off /Stop
Contents
WHAT IS WHAT? ........................................................4
WARNINGS AND SAFETY INSTRUCTIONS ............5
SPECIFICATIONS ......................................................7
ASSEMBLY PROCEDURES ......................................8
○
When transporting your chain saw, use the
appropriate guide-bar scabbard.
○
When a chain saw is being used, a fi re extinguisher
should be available.
OPERATING PROCEDURES .....................................9
MAINTENANCE .......................................................15
Parts breakdown
