TanGO TX1 - Page 55

49
Table 6.1 Tango TX1 parts list
Diagram
number
Part name Field
replaceable
Part
number
Notes
-- Case top assembly
Case top can be replaced as a
single assembly that includes
the parts labeled with diagram
numbers: 1, 15, 16, 17, 18,
and 19. Some components
also sold separately.
Yes 17153951 Assembly includes case top (17153952); sensor
support (17159184); sensor water barriers and
gaskets (17154219 and 17158903, respectively);
speaker dust barrier (18109613); and vibration
alarm motor (17127275).
1
Case top
Yes
17153952
15
Sensor support
Yes
17159184
Included with case top assembly; not sold
separately.
16 Sensor water barrier Yes 17154219 Parts 17154219 and 17158903 should be
replaced at the same time. Kit 18109230
contains 10 barriers and 10 gaskets.
17 Sensor water barrier gasket Yes 17158903
18 Speaker dust barrier kit Yes 18109613 Includes 10 speaker dust barriers. Notes: The
dust barriers are not water impenetrable. More
frequent replacement service may be needed in
harsh environments.
19
Vibration alarm motor
Yes
17127275
2
Sensors
Yes
Varies
CO
Yes
17155161
17155161A
b
Includes two sensors and polycarbonate plates.
H
2
S Yes 17155164
17155164A
b
Includes two sensors and polycarbonate plates.
NO
2
Yes 17155162 Includes two sensors and polycarbonate plates.
SO
2
Yes 17155163 Includes two sensors and polycarbonate plates.
CO / H
2
Low
Yes
17155823
Includes two sensors and polycarbonate plates.
7
Polycarbonate plate (not sold
separately)
Yes
—
Included with sensors above.
4
Battery
Yes
17154367
3 and 5
LCD
No
a
17153786
6 and 8 Board assembly
No
a
—
9
Case bottom
No
a
17153769
10 Case bottom screws Yes 17154328 Torque: 85 newton cm (120 ounce-force inch)
11 and 12
Unit labels
No
a
—
13 Garment clip Yes 17159205
not shown Audio alarm amplifier
(optional)
Yes 17154915
14 T10 Torx screw (for use with
installed garment clip)
Yes 17158205 Torque: 81 newton cm (115 ounce-force inch)
a
For items that are not field-replaceable, contact Industrial Scientific (see "Contact Information") or a local distributor of Industrial Scientific products.
b
The sensor is certified for use according to PFG 23 G 002 X for gas performance.
Note: For accessories storage specifications see Product Specifications.
