5. SPARE PARTS
Flap valves
11H
2
Housing
AISI316L
131H
1
Inlet manifold
AISI316L
132H
1
Outlet manifold
AISI316L
138
8
Tri-clamp
AISI304
17V
1
Stand
AISI304
18H
8
Sealing
PTFE, EPDM
241H
4
Flap valve seat
AISI316L
242H
4
Flap
AISI316L
24H
4
Flap valve complete
(241H+242H)
AISI316L
Ball cup valves
11C
2
Housing
AISI316L
131C
1
Inlet manifold
AISI316L
132C
1
Outlet manifold
AISI316L
138
8
Tri-clamp
AISI304
17V
1
Stand
AISI304
18F
8
Sealing
PTFE, EPDM
182
4
Stopper O-ring
FEP/FKM
22B
4
Valve ball stopper
AISI316L
24B
4
Ball valve cup
AISI316L
