TapFlo T30 - T825 Optional Spare Parts

5. SPARE PARTS
36
2
Centre block seal
PE
37
16
Pin screw nut
A4-70
371
32
Manifold screw nut
A4-70
38
16
Pin screw washer
A4-80
381
32
Manifold screw washer
A4-70
47
2
O-ring (back up for 36)
NBR
61
1
Air valve complete
PET/NBR (standard); AISI 316/FKM, Brass/NBR,
Brass/EPDM, AISI 316/FKM, PET/FKM
5.11. T825 – Spare parts options
Air valve reinforcement
122
1
Center block
PP
271
1
Set of 2 reinforcement
plates
AISI 316L
2711
8
Screws
A4-70
Flap valves
11H
2
Housing
AISI316L
13H
2
In/outlet manifold
AISI316L
138
8
Tri-clamp (DN100)
AISI304L
138H
4
Tri-clamp (DN150)
AISI304L
17H
1
Stand
AISI304L
18
8
Sealing (DN100)
EPDM
18H
4
Sealing (DN150)
EPDM
241H
4
Flap valve seat
AISI316L
242H
4
Flap
AISI316L
243H
4
Flap valve housing
AISI316L
24H
4
Flap valve complete
(241H+242H+243H)
AISI316L
