6. DATA
IOM manual Tapflo TF series 36
6.3. Technical data
TECHNICAL DATA
PUMP SIZE
TF50
TF100
TF200
TF400
Max capacity* [l/min] / [US GPM]
55 / 14.5
110 / 29
200 / 53
400 / 106
Volume per stroke** [ml] / [cu in]
87.5 / 5.34
280 / 17.1
933 / 56.9
2300 / 140.3
Max discharge pressure [bar] / [psi]
16 / 232
16 / 232
12 / 174
12 / 174
Max air pressure [bar] / [psi]
8 / 116
8 / 116
6 / 87
6 / 87
Max suction lift dry*** [m] / [Ft]
2.5 / 8
3.5 / 11
4 / 13
4 / 13
Max suction lift wet [m] / [Ft]
8 / 26
8 / 26
8 / 26
8 / 26
Max size of solids ø in [mm] / [in]
4 / 0.16
6 / 0.24
10 / 0.39
15 / 0.59
Max temp. pump in PE [°C] / [°F]
70 / 158
70 / 158
70 / 158
70 / 158
Weight of pump in PE [kg] / [lb]
8 / 17.6
21.6 / 47.6
49 / 108
78 / 172
TECHNICAL DATA
PUMP SIZE
TF70
TF120
TF220
TF420
Max capacity* [l/min] / [US GPM]
55 / 14.5
110 / 29
200 / 53
400 / 106
Volume per stroke** [ml] / [cu in]
87.5 / 5.34
280 / 17.1
933 / 56.9
2300 / 140.3
Max discharge pressure [bar] / [psi]
16 / 232
16 / 232
14 / 203
12 / 174
Max air pressure [bar] / [psi]
8 / 116
8 / 116
7 / 101.5
6 / 87
Max suction lift dry*** [m] / [Ft]
3 / 9.8
4 / 13
4 / 13
4 / 13
Max suction lift wet [m] / [Ft]
8 / 26
8 / 26
8 / 26
8 / 26
Max size of solids ø in [mm] / [in]
4 / 0.16
6 / 0.24
10 / 0.39
15 / 0.59
Max temperature with EPDM/NBR [°C] / [°F]
80 / 176
80 / 176
80 / 176
80 / 176
Max temperature with PTFE [°C] / [°F]
110 / 230
110 / 230
110 / 230
110 / 230
Weight in aluminium [kg] / [lb]
11 / 24.3
16.3 / 35.9
35 / 77.2
51.6 / 113.8
Weight in AISI 316 [kg] / [lb]
16 / 35.3
23.5 / 51.8
51.6 / 113.8
69 / 152.1
* = Max flow is obtained when using a bypass around the pressure booster at low pressure.
** = Based on pumps with EPDM diaphragms. Pumps with PTFE diaphragms have about 15% less volume.
*** = With stainless steel valve balls, other materials may reduce suction. Please consult us in this matter.
