27
Skip Playback
During playback press [ / ] repeatedly during playback
to skip to previous or next track/chapter.
Slow Motion Playback
1. During playback, press SLOW repeatedly to select the
forward (or reverse) slow speed playback.
The playback speed changes as follows :
For DVD / DVD+/- RW / DVD+/-R / MPEG4 discs
SF2X SF4X SF8X PLAY 6R2X SR4X SR8X
PLAY SF2X
2. Press PLAY/PAUSE
/ to return to normal playback.
Step Playback ( Frame by Frame Advance Playback )
For DVD-Video / DVD+/-RW / DVD+/-R / MPEG4 discs
1. During playback, press Step repeatedly to view playback frame
by frame. Each time the button is pressed, the picture advances
one frame.
2. Press
/ to return to normal playback.
Repeat Playback
Press REPEAT during playback (or programmed playback) of
the title (or track ) you want to repeat. Each time the button is
pressed , the repeat mode will be changed as follows :
For DVD / DVD+/-RW / DVD+/-R discs
CHAPTER REPEAT ON:
Repeat of the chapter being played
TITLE REPEAT ON:
Repeat of the title being played
REPEAT OFF
Normal playback mode
For VCD / CD discs
REP-ONE:
Repeat of the track being played
REP-ALL:
Repeat all tracks
REPEAT OFF:
Normal playback mode
A-B Repeat Playback
This function can play a specific section in a chapter/track
repeatedly.
1. Press A - B at the starting portion you want.
2. Press A - B again at the end portion you want. The specific
section will now repeat continuously.
3. Press A - B the third time to return to normal playback.
Notes :
The A and B can be set only within the same chapter/track.
After performing repeat play, be sure to press the STOP button .
Otherwise , the disc will play continuously.
Using DVD TITLE menu
Some DVDs may contain two or more titles. If the disc has a title
menu recorded on it, you can start playback from the selected
movie title.
1. Press TITLE , The title menu screen will appear (if the disc
contains it).
2. Press
/ / / (or the number buttons ) to select the desired
menu.
3. Press ENTER to playback the selected menu.
Using MENU/PBC
For VCD / CD discs
Press this button to turn the MENU ON or OFF.
1. The system will set the PBC function to ON automatically and
showing PBC menu.
2. Press MENU/PBC to switch PBC OFF( If the disc is playing, the
playback will stop), using numeric key (0~9, >10) to select the
track you want to playback.
For DVD / DVD+/-RW / DVD+/-R disc
Press this button to make the playback go back to the title menu
of disc. “ROOT MENU ” will appear on OSD for 2 seconds.
Note : When the PBC is set to ON , you can not use the
numeric buttons to select track directly.
Return ( Go back to the menu screen )
Press RETURN when playing a VCD disc with PBC .The Go BACK
TO MAIN PAGE is shown on the TV screen, and then the menu
appears.
GOTO ( Title, Chapter, Track or Time search )
This function allows you to start playing at any title, chapter, track
or time on the disc.
For DVD / DVD+/-RW / DVD+/-R discs
1. Press GOTO.
2. Press
/ to select TITLE or CHAPTER search or press GOTO
again to enter time search.
eg :TITLE 01 / 28 CHAPTER 015 / 035
TITLE 01 / 02 TIME — : — : —
3. Use numeric key (0~9, >10) to input the specific title, chapter or
elapsed playing time at which you want to begin playback.
4. Press ENTER.
For VCD / CD discs
1. Press GOTO.
2. Use numeric key (0~9, >10) to input the specific elapsed playing
time at which you want to begin playback.
eg : GOTO —:—
