Target hamilton - Step 4: Attaching the Right Side Frame

10
step 4: attach right side frame
(H1) x 8
wooden dowel
(H2) x 5
cam bolt
(H3) x 5
cam
(H9) x 1
mini screwdriver
(H10) x 2
pan head screw
4.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
4.2. Screw-In cam bolts must be screwed down ush.
4.3. Refer to page 6 for instructions on how to use the cam lock system.
4.4. Do not over tighten bolts.
4.5. Do not over tighten screws.
