Target hamilton - Step 2: Attaching the Top Panel

8
step 2: attach top panel
(H1) x 2
wooden dowel
(H2) x 8
cam bolt
(H3) x 8
cam
(H9) x 1
mini screwdriver
2.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
2.2. Screw-In cam bolts must be screwed down ush.
2.3. Refer to page 6 for instructions on how to use the cam lock system.
2.4. Do not over tighten bolts.
