Target hamilton - Step 6: Installing the Drawer Support

12
step 6: attach drawer support
(H1) x 2
wooden dowel
(H8) x 1
small cam bolt
(H7) x 1
small cam
(H9) x 1
mini screwdriver
6.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
6.2. Screw-In cam bolts must be screwed down ush.
6.3. Refer to page 6 for instructions on how to use the cam lock system.
6.4. Do not over tighten bolts.
Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
