4
hardware
(H1) x 30
wooden dowel
(H2) x 22
cam bolt
(H3) x 22
cam
(H4) x 8
at head screw
(H5) x 2
knob bolt
(H6) x 2
knob
(H7) x 2
small cam
(H8) x 2
small cam bolt
(H9) x 1
mini screwdriver
(H10) x 2
pan head screw
(H11) x 1
19mm pan head screw
(H12) x 1
wall strap
(H13) x 1
wall anchor
(H14) x 1
38mm wall screw
(H15) x 2
5/8” washer
