Target hamilton - Step 10: Anti-Tip Kit Installation

step 10: install anti-tip kit
(H11) x 1
19mm pan head screw
(H12) x 1
wall strap
(H15) x 2
5/8” washer
(H13) x 1
wall anchor
(H14) x 1
38mm wall screw
Position against wall
Mark position of strap hole on
wall
Drill 1/4’’ hole
Tap in wall anchor
Fasten anti-tip strap
with at-head screw provided
16
(H12)
(H15)
(H11)
(H14)
(H15)
(H13)
(H14)
(H15)
(H13)
