Target hamilton - Step 7: Attaching the Drawer Back

step 7: attach drawer back
(H1) x 2
wooden dowel
(H8) x 1
small cam bolt
(H7) x 1
small cam
(H4) x 4
at head screw
(H9) x 1
mini screwdriver
7.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
7.2. Screw-In cam bolts must be screwed down ush.
7.3. Refer to page 6 for instructions on how to use the cam lock system.
7.4. Align screws with pre-drilled holes.
7.5. Do not over tighten screws.
Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
