Task Force Tips SAFE-TAK 1250 User Manual

©Copyright Task Force Tips, Inc. 2002-2018 LIX-030 January 8, 2018 Rev24
8
4.10.4 PRESSURE LOSS
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000
LOSS (BAR)
FLOW (L/MIN)
CROSSFIRE Top with
Safe-Tak 1250 Base
CROSSFIRE Top
0 200 400 600 800 1000 1200
FLOW (GPM)
0
10
20
30
40
50
60
70
LOSS (PSI)
Figure 4.10.4
4.10.5 OPERATING ENVELOPE
0 1000 2000 3000 4000 5000
0
5
10
15
20
25
0
50
100
150
200
250
300
350
400
0 200 400 600 800 1000 1200 1400
Flow (l/min)
Pressure (BAR)
Pressure (PSI)
Flow (GPM)
1 3/8" (35mm) Tip
2.0" (50mm) Tip
1 1/2" (38mm) Tip
1 3/4" (44mm) Tip
Maximum Monitor
Inlet Pressure
Maximum Nozzle
Inlet Pressure
Figure 4.10.5
4.11 TRANSPORTING MONITOR ON TRUCK MOUNT BASE
If the monitor is to be transported on a truck mount base, the horizontal lock should be kept locked to keep the monitor from spinning
on its base. The rotational position can be locked by moving the rotation lock lever to its down position. The nozzle may be supported
by a bracket or pointed straight up.
