40
Technical data
Accessories
Error codes
Error codes are indicated on the display.
Loading and transport
Disposal
Batteries
Machine
Working width 70 cm
Suction nozzle / squeegee
width
90 cm
Dimensions (L x W x H) 135 x 90 x 129 cm
Maximum weight of opera-
tional machine
471 kg
Rated voltage 24V DC
Rated power, nominal 1500 W
Fresh water tank, nominal
+/- 5%
90 l
Values according to IEC
60335-2-72
Machine weight with batter-
ies (transport weight)
376 kg
Sound pressure level LpA 70 dB(A)
Uncertainty KpA 2.5 dB(A)
Vibration (Manual mode) < 2.5 m/s2
Uncertainty K 0.25 m/s2
Splash water guard IPX3
Protection class III
No. Item
8501120 Pad drive harpoon grip 35 cm 2x
8501080 Scrubbing brush, nylon, 35 cm 2x
8501060 Scrubbing brush, washed con-
crete, 35 cm
2x
8502750 Scrubbing brush, abrasive, 35 cm 2x
7524346 Battery tray x
7524347 Battery tray RTU (ready-to-use) x
7524344 Battery box (without batteries) x
7524345 Battery box (with batteries) x
Various pads (polyester brown,
blue, red and contact pad)
x
Notice:
Switch the machine off and on again
whenever an error code occurs.
Error codes might be remedied by switch-
ing the machine off and on.
Notice:
You can find a list of the error codes and
their meaning in the Service Tool Manual.
Attention:
Prior to loading for transport, the following
must be done:
- the machine must be switched off,
- the fresh water and the recovery tank
must be emptied completely.
Attention:
When loading the machine via the ramp, it
must be lifted up. Pull the release lever to
do this (please see the structural layout on
page 31).
Attention:
This machine may only be lifted using lift-
ing gear (e.g. hoist, loading ramp, etc.).
Notice:
Transport the machine in an upright posi-
tion.
Notice:
Make sure that the machine is securely
tied down in the transport vehicle.
Notice:
After withdrawal from service, the machine
and accessory parts must be adequately
disposed of in compliance with the nation-
al regulations. Please contact your Di-
versey service partner for help.
Attention:
Remove all batteries from the machine pri-
or to disposal.
Used batteries must be disposed of in an
environmentally friendly way in compli-
ance with the EC directive 2006/66/EC or
the respective national regulations.
