D760M
7 MAN MODE
On
Off Normal function
WARNING: with dip 7 ON the input OPEN / CLOSE (terminals 11-12) switches OPEN, the
PEDESTRIAN input (terminals 11-13) switches CLOSE.
In MAN mode, it is not necessary to run the race setup, and the dip-switches 1, 2, 3 and
4 are not used.
8 2nd RADIO CH
On
is activated and remains activated until the next pressure.
Off
9
OPENING
RAM BLOW
On
of the electric lock (to be used only in the presence of an electric
Off
10
SENSITIVE EDGE
SELECTION
On
Off
Note: if not used, keep the DIP in the OFF position.
JUMPER J1
closes automatically after 5 seconds.
IMPORTANT:
ensure the proper operation of the board.
-
433.92 MHz BUILT-IN RADIO RECEIVER
The radio receiver can learn up to a maximum of 30SLIM-RP, T-
4RP
4_ LED DL7 turns on again to indicate that the code has been memorised (if this does not happen,
5_ to memorise codes to other radio control devices, repeat the procedure from point 1 up to a maxi-
mum of 30
Notice: if the maximum number of radio control devices (30
rapidly for about 3 seconds without memorising the code.
