tau K100M User Manual

With the V 4.X software version it is possible to carry out remote learning with remote controls T-4RP and K-SLIM-RP (V 4.X),
that is without acting directly on the programming keys of the receiver.
It will be sucient to have an already programmed remote control in the receiver and you will be able to open remote pro-
gramming of the new remote controls. Follow the procedure in the instructions of the T-4RP and K-SLIM-RP (V 4.X) remote
controls.
ERASING ALL PROGRAMMED TRANSMITTERS
1_ press and hold the RADIO button on the control unit for approx. 3” to start the erasing procedure;
2_ DL1 LED ashes slowly to indicate that the erasing procedure has been activated;
3_ again, press and hold the RADIO button on the control unit for approx. 3”;
4_ DL1 LED turns o for approx. 3”, then turns ON To indicate that all stored codes have been cancelled;
5_ repeat the procedure in point 1 using the RADIO+OP/CL keys together to cancel all the controls associated with the PEDES-
TRIAN control;
6_ to exit the erasing mode, press and release RADIO button.
MEMORY CAPACITY
The code memory capacity* of the K100M can be expanded from 30 to 126, 254 or 1022 codes (transmitters) by replacing the
memory cards as follows (plug them onto SM connector, see wiring diagram) :
126 codes Art. 250SM126
254 codes Art. 250SM254
1022 codes Art. 250SM1022
* Control units are supplied with a standard built-in 30-code memory. The memory card for enhancing the code memory capacity
must be ordered separately.
To allow the previously stored codes (max. 30) to be moved to the control unit, it is required to install a memory card, making
sure that the control unit is at that time o and that the memory card is brand new and therefore completely empty.
When the control unit is restarted, the codes will automatically move to the memory card.
Moving the codes from the control unit to the memory card does not work if on the memory card used, radio control codes
have already been stored and the memory card has been subsequently erased.
To insert new radio controls, the operation described above shall be repeated.
WARNING: Control unit must be turned OFF to insert / remove a memory card.
RADIO MEMORY HARD RESET:
- press without releasing keys RESET+RADIO till LED DL1 starts ashing quickly. At this point release the keys and press them
again till the LED go o and on again, conrming the operation is complete.
RADIO MEMORY WRITING VIA TAUSOFT
To enable writing the radio memory with TAUSOFT, keep keys RADIO+OP/CL pressed while you connect the cable to connector
“SM” of K100M and keep them pressed until DL1 stops ashing. For information regarding radio programming with TAUSOFT,
refer to the relative manual.
SET-UP FOR OPERATION WITH TAU APPS
In order to use the TauApp and TauOpen apps, it will be necessary to connect to input J4 of the K100M control unit using the
supplied cable, the respective T-WIFI and T-CONNECT devices. To activate the operation of the apps see the respective instructions.
TROUBLESHOOTING GUIDE
Operator does not run
a- Check 230/115 V power supply with a voltmeter;
b- Check that all 4 green LEDs (Normally Closed contacts, DL3, DL4, DL5 and DL6) are ON, and that DL2 LED (Normally Open contacts) is
OFF. LED DL1 must be ON;
c- Check that the red DL1 LED is ON;
d- Check that the fuses are intact with a voltmeter.
The radio control has little range
a- Check that the ground and the aerial signal connections have not been inverted;
b- Do not make joints to increase the length of the aerial wire;
c- Do not install the aerial in a low position or behind walls or pillars;
d- Check the state of the transmitter’s batteries.
The gate opens the wrong way
a_ Invert the position of DIP 4 (after having turned o the power to the control unit).

tau K100M Specifications

General

Brand	tau
Model	K100M
Category	Control Panel
Language	English
