17
K125M
N.B.: to be used when the photocells are not used.
Gate contact open:
Bistable function active:
Monostable function active for 2 sec.:
Monostable function active for 180 sec.:
Check the mains power supply, charge the battery, replace the battery;
Disable phototest (dip-switch 6 OFF), check operation and connection of photocells;
Check the thermal-magnetic circuit breaker (upstream from system), check the fuses;
Gearmotor has exceeded absorption limits, check for obstacles across the path of the gate, check
the current absorption of the motor when loadless and under load;
Check wiring, check encoder through TEST-ENCODER (optional), verify that the motor turns
freely if powered directly by the battery, check fuse F2;
Make sure there are no obstacles across the path of the gate and that it slides smoothly;
Execute memorization procedure.
check wiring, check that the motor rotates freely when powered directly by battery, check fuse F2.
