K570M
CONTROL PANEL FOR ONE 230 Vac MOTOR
• MICROPROCESSOR-CONTROLLED LOGIC
• INPUT STATUS LED’S
• LINE INPUT FUSE
• “PEDESTRIAN ENTRY” FUNCTION
• BUILT-IN FLASHING LIGHT CIRCUIT
• WEEKLY TIMER INPUT
• 433.92 MHz 2 CHANNEL BUILT-IN RADIO RECEIVER (CH)
• OPERATING TIME FIXED AT 120 sec.
• AUTOMATIC DETECTION OF THE FEEDING FREQUENCY (50 or 60 Hz)
ATTENTION:
- do not use single cables (with one single wire), ex. telephone cables, in order to avoid
breakdowns of the line and false contacts;
- do not re-use old pre-existing cables.
TESTING
When you have completed the connection:
• All the green LS LEDs must be on (each of them corresponds to a Normally Closed input).
The go off only when the controls to which they are associated are operated.
• All the red LS LEDs must be off (each of them corresponds to a Normally Open input). The
light up only when the controls to which they are associated are operated.
TECHNICAL CHARACTERISTICS
Power input to board 230V AC - 50 Hz
Nominal power 400 W
Fast acting fuse for protection of input power supply 230 Vac (F1 - 5x20) F 3,15 A
Input voltage of motor circuits 230V AC
Input voltage of auxiliary circuits 24V AC
Fast acting fuse for protection of auxiliary circuits 24 V dc (F2 - 5x20) F 500 mA
Working temperature -20°C ÷ +55°C
Box protected to IP 44
DIAGNOSTICS LED
DL1 PHOTOCELL green LED signal
DL2 SENSITIVE EDGE green LED signal
DL3 CLOSE LIMIT SWITCH green LED signal
DL4 OPEN LIMIT SWITCH green LED signal
DL5 STOP button green LED signal
DL6 PEDESTRIAN button red LED signal
DL7 OPEN/CLOSE button red LED signal
DL8 RADIO CONTROLS programming red led
TERMINAL BOARD CONNECTIONS
Terminals Function Description
1 - 2 - 3 POWER SUPPLY
POWER input 230 Vac 50Hz (115 Vac 60 Hz).
1= PHASE 2= EARTH 3= NEUTRAL;
4 - 5 FLASHING LIGHT
FLASHING LIGHT output 230 Vac 50 W max. The signal is
already modulated for direct use. Flashing frequency increases
slightly during closing;
