9.3 Parts list
No. Description Qty. No. Description Qty.
1 Main Frame 1 32 Battery Door 1
2 Front Stabilizer 1 33 Console Bracket 1
3 Rear Stabilizer 1 34 Upper Handlebar Decoration Cover 1
4 Seat Post 1 35 Lower Handlebar Decoration Cover 1
5 Upright Post 1 36 Accessory Tray Support Pad 1
6 Handlebar 1 37 Accessory Tray 1
7 Left Cover 1 38 Left Upright Post Sleeve 1
8 Right Cover 1 39 Right Upright Post Sleeve 1
9 Upper Chain Cover 1 40 Front Aluminum Upright Cover 1
10 Crank Cover 2 41 Rear Aluminum Upright Cover 1
11 Left Pedal 1 42 Air Pressure Bar 1
12 Right Pedal 1 43 Seat Adjustment Lever 1
13 Belt (762J8) 1 44 Fixed Stand 1
14 Belt (1092J8) 1 45 Spacer 1
15 Pulley (235) 1 46 Cable 1
16 Magnet 1 47 Cable Spring 1
17 Pulley (120) 1 48 Roller Axle 1
18 EndCaps 4 49 Stand Spring 1
19 Leveler 4 50 Spacer Stand 1
20 Transportation Wheels 2 51 Arc Washer 1
21 Seat 1 52 Resistor 1
22 Seat Lower Case 1 53 Controller 1
23 Adjustment Bar 1 54 Right Mounting Plate 1
24 Slider 1 55 Left Mounting Plate 1
25 Seat Post Sleeve 1 56 Generator 1
26 Upper Foam Grip 2 57 Adaptor Bracket 1
27 Foam Grip 2 58 One Way Pulley (51) 1
28 Hand Wrist Pad 2 59 One Way Bearing(2520) 1
29 Pulse Sensor Top Housing 2 60 Axle 1
30 Pulse Sensor Bottom Housing 2 61 Crank Shaft 1
31 Console 1 62 Left Crank 1
