4
Introduction
Models 150, 152, 162, 168
Model 150 Specifications
Freezing Cylinder
One, 1.5 quart (1.4 liter).
Mix Hopper
One, 8 quart (7.6 liter).
Beater Motor
One, 0.5 hp.
Refrigeratio n Unit
One, approximately 3,000 btu/hr. compressor.
Refrigerant: R404A.
One, independent SHR compressor, approximately
400 btu/hr. R134a. (BTU’s may vary based on
compressor used.)
Electrical
Electrical
Total
Amps
Supplied With
115/60/1 Air 16.0 20 amp. cord and plug
208-230/60/1 Air 10.2 15 amp. cord and plug
This unit is manufactured in other electrical
characteristics. Refer to the Distributor Data Book for
availability. (For exact electrical information, always
refer to the data label of the unit.)
Air Cooled
Clearance: 6” (15.2 cm.) around both sides. Install the
skirt provided onthe right side of the unit and place the
back of the unit against a wall to prevent recirculation
of warm air.
Dimensions
Width: 14-1/16” (35.7 cm.)
Depth: 24” (61.0 cm.)
Height: 51-1/2” (130.8 cm.)
Floor Clearance: 3-11/16” (9.4 cm.) mounted on
standard casters.
Approximate Weights
Net: 250 lbs. (113.4 kgs.)
Crated: 310 lbs. (140.6 kgs.)
23.0 cu. ft. (.65 cu. m.)
