3
Model 161
Introduction
071018
Model 161 Specifications
Freezing Cylinder
Two, 1.5 quart (1.4 liter) volume.
Mix Hopper
Two, 8 quart (7.6 liter) capacity.
Beater Motor
Two, 0.5 hp.
Refrigeration Unit
One, 8,000 BTU/hr compressor. R404A.
Separate Hopper Refrigeration (SHR), one 300
BTU/hr. R134a. (Actual BTU’s may vary based on
application.)
Electrical
Electrical
Total
Amps
Supplied with
NEMA Cord
208-230/60/1 Air 10.0 6-15P
220-230/60/1 Water 10.0 6-15P
220-240/50/1 Air 15.0 ---
220-240/50/1 Water 15.0 ---
This unit may be manufactured in other electrical
characteristics. Refer to the local Taylor Distributor
for availability. (For exact electrical information,
always refer to the data label of the unit.)
Air Cooled
Clearance: 6” (152 mm) on left and right, and 0” in
the rear. Install the air deflector provided and place
the rear of the unit against the wall to prevent
recirculation of warm air. Minimum air clearances
must be met to assure adequate air flow for
optimum performance.
Dimensions
Width: 21-1/8” (537 mm)
Depth: 26-5/8” (677 mm)
Height: 28-1/8” (715 mm)
Counter Clearance: Designed to rest on a plastic
pad directly on the counter top or optional cart.
Approximate Weights
Net: 305 lbs. (138.3 kgs.)
Crated: 355 lbs. (161.0 kgs.)
Volume: 17.9 cu. ft. (0.51 cu. m.)
Availability and specifications are subject to
change without notice.
This unit is designed and constructed to meet
stringent safety and sanitation requirements for NSF
and UL.
