Taylor 390 Service Manual

4.8 BEVERAGE EQUIPMENT:
4.8.6.3 Iced Cappuccino Machine 2 Issue Date: February 21, 2008
Taylor 390 Last Modified: October 31, 2008
OPERATOR PARTS IDENTIFICATION
Item Description
Part
Number
1
Hopper Cover X51152
2
Rear Panel 047008
3
Top Side Louver 051192
4
Air Duct X53073-1
5
Right Side Panel X52595
6
Screw 011694
7
Base Pan Gasket 050947
8
Base Pan Gasket Insert 051150
9
Spinner X66023-27
10
Drip Tray 046275
11
Wire Splash Shield 046177
12
Drip Pan 035034
13
Side Panel (Lower Left) 050935
14
Front Spinner Panel X66589
15
Nose Cone Stud 013496
16
Left Side Panel (Upper) 042317
This unit has a 20 quart (18.9 Litre) mix hopper and the freezing cylinder holds 7
quarts (6.6 Litres) of Iced Cappuccino Mix (equivalent of three batches total).
