6-8
OPERATING PROCEDURES
Models C001 and C002
Operating Procedures
6
5. Remove the O-rings from the inner flow regulators.
Figure 6-21
6. Remove the hopper cover gasket from the hopper
cover.
7. Return to the freezer with a small amount of cleaning
solution. Brush-clean the mix inlet holes in the mix
hoppers.
Figure 6-22
8. Brush-clean the rear shell bearings at the back of the
freezing cylinders with the black bristle brush.
Figure 6-23
9. Thoroughly brush-clean all disassembled parts in the
cleaning solution, making sure all lubricant and mix
film is removed. Place all the cleaned parts on a
clean, dry surface to air-dry overnight.
10. Wipe clean all exterior surfaces of the freezer.
