Taylor C707 User Manual

8
Model C707Operator Parts Identification
140618
Model C707 Single Spout Door and Beater Assembly
ITEM DESCRIPTION PART NO.
1 DOOR A. - W/BAFFLE X56071 - SER
1a BAFFLE A.- LONG 4 IN X50882
2 HANDLE A. - DRAW- WELDED X56246
3 SCREW- ADJUSTMENT 056332
4 O- RING- 1/4 OD X .070W 50
DUROMETER (25 TO BAG)
015872
5 PIN- HANDLE- SS 055819
6 PLUG- PRIME 028805
7 O- RING- 3/8 OD X .070W
(100 TO BAG)
016137
8 VALVE A.- DRAW X56072
ITEM DESCRIPTION PART NO.
9 O- RING- 7/8 OD X .103W
(100 TO BAG)
014402
10 NUT- STUD- LONG 058765
11 NUT - STUD 058764
12 GASKET- DOOR HT 4”- DBL 048926
13 BEARING- FRONT 050216
14 BEATER A.- 3.4QT X31761
15 BLADE- SCRAPER- PLASTIC 035174
16 SHAFT- BEATER 056078
17 SEAL- DRIVE SHAFT 032560

Taylor C707 Specifications

General

Power	208-230V, 60Hz, 1Ph
Minimum Clearance	6" on both sides
Water Inlet	3/8" FPT (Water Cooled)
Water Outlet	3/8" FPT (Water Cooled)
Separate Hopper Refrigeration	Maintains mix below 41ºF (5ºC) during Auto and Standby modes.
