Section 12 Parts List
33
+ Available Separately
Model C707 Parts List
140630
DESCRIPTION PART
NUMBER
C707
QTY.
W ARR.
CLASS
REMARKS
ACCUMULATOR- COPPER 2”DIA 10” 047062 1 103 RECEIVER REFRIGERANT
BEARING- FRONT 050216 1 000
BEARING- REAR SHELL *NICK.PLATE 031324 1 000
+GUIDE- DRIP SEAL 028992 1 000
+NUT - BRASS BEARING 028991 1 000
+O- RING- 1/2OD X .070W 024278 2 000
+WASHER- BEARING L OCK 012864 1 000
BEATER A. - 3.4QT- HELICORE X31761 1 103
+BLADE- SCRAPER - PLASTIC 17L 035174 2 000
BELT - AX41 023876 2 000 208- 230V 60HZ 1PH - 208 - 230V 60HZ 3PH
BLOCK- TERMINAL 2P- L1,L2 039422 1 103 208- 230V 60HZ 1PH
BLOCK- TERMINAL 3P- L1,L2,L3 039423 1 103 208- 230V 60HZ 3PH
BOARD- LOGIC- GEN 2.11 SD/CHM/DF X69571SER2 1 212 S/N M3125282 & UP - REPLACES X69570SER2 &
X36641SER2 U/D 233
+SWITCH- MEMBRANE- 5 POSITION 043217 1 000
BOARD- POWER - GEN 1 & 2 X69574 - SER 1 212 REPLACES X32326- SER - M2044528
FUSE- .063A- 250V- 5X20MM- SLO BLO 051272 1 000
BRUSH- REAR BRG 1IN.DX2IN.LGX14 013071 1 000
BRUSH- DOUBLE ENDED- PUMP&FEED T 013072 1 000
BRUSH- DRAW VALVE 1”ODX2”X17”L 013073 1 000
BRUSH- END- DOOR- SPOUT - SS - HT 039719 1 000
BRUSH- MIX PUMP BODY- 3”X7”WHITE 023316 1 000
BRUSH- SET LVB 050103 1 000
BRUSH- PUMP SPOUT *MC13* 054068 1 000
CABLE- RIBBON- PWR/RELAY 069558- 60 1 103 REPLACES 056295
COMPRESSOR L64A113BBCA 048259- 27E 1 512 208 - 230V 60HZ 1PH - BRISTOL K7026650 & UP - REPLACES
047519- 27F
+CAPACITOR - START 189- 227UF/330V 033044- 1 1 103
+CAPACITOR - RUN 25UF/440V 037431 1 103
+RELAY - START- COMPRESSOR 062363 1 103
+GROMMET - COMPRESSOR MOUNT- AH 039923 4 000
+SLEEVE- MOUNTING- COMP.- AH 039924 4 000
