+ Available Separately
34
Parts List Model C707
DESCRIPTION REMARKSW ARR.
CLASS
C707
QTY.
PART
NUMBER
COMPRESSOR AHA2490ZXD - AH556EF 047519- 27F 1 512 N/A USE 048259- 27E - 208 - 230V 60HZ 1PH - TECUMSEH
K7015617 & PRIOR
+CAPACITOR - RUN - 35UF/440V 048132 1 103 +CAPACITOR - START- 130- 156UF/330V 036048 1 103 +RELAY - START- COMPRESSOR 036047 1 103
COMPRESSOR L63A113DBLA 048259- 33 1 512 208- 230V 60HZ 3PH S/N K7026650 - BRISTOL REPLACES
047519- 33F
COMPRESSOR AHA2490ZXF- AH556RF 047519- 33F 1 512 N/A USE 048259 - 33 - 208- 230V 60HZ 3PH S/N K7015617 &
PRIOR - TECUMSEH
COMPRESSOR PL35G 055187- 27 1 512 SHR
+RELAY - START- COMPRESSOR 055358 1 103 +CAPACITOR - START 60UF- 220/275 047703 1 103
CONDENSER- AC- 15LX14HX2.59T- 3RW 046558 1 103 MAIN REFRIGERATION CONDENSER- AC - 7X6X1.25- 2 ROW 027155 1 103 SHR COUPLING- DRIVE 3/4 HEX X 1- 7/8 012721 1 103 COVER- HOPPER COMPLETE (Black) 1 103 SEE KIT X65368- SP KIT A. - COVER- GIOOER*SINGL -
K2010000/up using Black Cover U/D 167
+PIN- RETAINING- HOPPER COVER 043934 4 103 U/D 167
DECAL - DEC- TAYLOR C707 057312 1 000 DECAL - INST- CLN HPR 019029 1 000 DECAL - TROUBLESHOOT 038374 1 000 DIAGRAM- WIRING *C706*C707* 064288- 27 1 000 208 - 230V 60HZ 1PH S/N K7026650 & UP - BRISTOL -
REPLACED 056352- 27
DIAGRAM- WIRING *C706*C707* 064288- 33 1 000 208 - 230V 60HZ 3PH S/N K7026650 & UP - BRISTOL -
REPLACED 056352- 33
DIAGRAM- WIRING *C706*C707* 056352- 27 1 000 N/A SEE 064288- 27 - 208- 230V 60HZ 1PH S/N K7015617 &
PRIOR - TECUMSEH
DIAGRAM- WIRING *C706*C707* 056352- 33 1 000 N/A SEE 056352- 33 - 208- 230V 60HZ 3PH S/N K7015617 &
PRIOR - TESUMSEH
DOOR A.- W/BAFFLE *C706* X56071- SER 1 103
+HANDLE A.- DRAW- WELDED *C706* X56246 1 103 +SCREW- ADJUSTMENT- 5/16- 24 *602* 056332 1 103
+O- RING- 1/4 OD X .070W 50 DURO 015872 1 000
+GASKET - DOOR HT 4” 048926 1 000 +PIN- HANDLE- SS *C602* 055819 1 103
