4-4
PARTS
Models C709 & C717
Parts
4
Model C717 Exploded View Parts Identification
Item Description Part No.
1 Cover-Hopper 053809-1
2 Blade A.-Agitator X56591
3 Orifice 022465-100
4 Tube A.-Feed-SC-Inner-3/16 X32824-3
5 Tube A.-Feed-Outer-HT X34641
6 O-ring-.643 OD X .077 W 018572
7 Panel-Rear 059917
8 Panel-Side-Right 059907
9 Pan-Drip 12.5 059736
10 Panel A.-Front (Middle) X63879
11 Stud-Nose Cone 055987
12 Panel A.-Front (Upper) X59836
13 Filter-Air-Poly-FLO 052779-11
Item Description Part No.
14 Panel A.-Filter-Louvered X59928
15 Caster-4” SWV 3/4-10 Stem 044106
16 Screw-1/4-20 X 3/8 RHM-SS 011694
17 Panel-Corner-Front R. 063087
18 Caster-4” SWV 3/4-10 Stem w/
Brake
046437
19 Deflector-Blower 059929
20 Shield-Splash-Wire-19-3/4 L 033813
21 Panel A.-Front Lower X59854-SER
22 Tray-Drip-19-5/8 L X 4-7/8 033812
23 Pan-Drip 19-1/2 Long 035034
24 Panel-Corner-Front-Left 063088
25 Panel-Side-Left 059906
26 Pin-Retaining-Hopper CVR 043934
To Next Page
