OPERATING PROCEDURES
6-9
Models C709 & C717
Operating Procedures
6
Note: Use warm water and follow the
manufacturer's specifications.
Sanitize the drip pans, feed tube assembly(ies),
agitator(s), and hopper cover(s).
7. Install the agitator(s) back onto the agitator
driveshaft housing(s).
Important! Make sure the agitator(s) are installed
and the switch is in the Auto or Standby mode, or the
machine will not have a successful Heat cycle.
8. Install the feed tube assembly(ies). Lift and turn the
inner feed tube of each assembled feed tube so the
pin rests on top of the outer feed tube. This action
closes the hole in the assembled feed tubes,
preventing mix in the hopper(s) from entering the
freezing cylinder(s) during the Heating and Standby
process.
Figure 6-33
9. Replace the hopper cover(s) and install the drip
pans.
10. Return to the freezer with a small amount of cleaning
solution. Dip the door spout brush into the cleaning
solution and brush-clean the door spout(s) and the
bottom of the draw valve(s).
Note: To ensure sanitary conditions are maintained,
brush each item for 60 seconds, repeatedly dipping
the brush in cleaning solution.
Figure 6-34
11. Using a clean, sanitized towel, wipe down the freezer
door, front panel, the area around the bottom of the
freezer door, and any other areas with a buildup of
either moisture or food substance.
The Heat cycle starts when the clock on the machine
reaches the Auto Heat Time set in the Manager's
Menu.
There are three phases of the Heat cycle: heating,
holding, and cooling. Each phase has a time limit. If
any one of the three phases fails to reach the proper
temperatures within the time limit, the cycle
automatically ends and returns to the Standby mode.
A failure message appears on the fluorescent display
to inform the operator that the machine did not
successfully complete the Heat Treatment cycle. The
product may not be safe to serve. The freezer is
locked out (soft lock) of the Auto mode. The operator
is given the option of selecting the Heat key ,
which begins a new Heat cycle, or pressing the Wash
key / , which places the freezer in the Off mode
to allow a brush-clean of the machine.
Note: Once the Heat cycle has started, the process
cannot be interrupted. The Heat cycle takes a
maximum of 4 hours to complete with full hoppers.
Important! Do not attempt to draw product or
disassemble the machine during the Heat cycle. The
product is hot and under extreme pressure.
When the Heating cycle is complete, the machine
returns to Standby mode. The Standby key(s)
illuminate.
12219
