Controls, Systems and Operations
Model C723
131028
Jumper Pin Chart - UVC4
Feature Left Interface
X53451-SER
Right Interface
X53451-SER
Force Brush Clean Status W2
Syrup Heater Enable W3
Open All Left Solenoids W4
Open All Right Solenoids W4
Clock/Calendar Override W5
Force Glycol Pump On
59F Fault Detection Enable W2**
Standby Stir Cycle Disable W5
Reduced Mix Low Sensitivity
Reduced Mix Out Sensitivity
7C/45F 90 Min. Cool Phase
Unused
Unused
Disable Control Panel (Self Serve) J10 - 7 & 8
** Jumper initially installed at factory.
UVC4 Control Feature Jumper
>41F for 4 hours & >45 for 1 hr JP1 - 1 & 2**
Reserved (do not install) JP1 - 3 & 4
Domestic/International (Note 3) JP2 - 1 & 2 **
Reserved (do not install) JP3 - 1 & 2
Reserved (do not install) JP4 - 1 & 2
Proximity Sensor (Note 4) JP5 - 1 & 2**
Reserved (do not install) JP6 - 1 & 2
Reserved (do not install) JP7 - 1 & 2
Reserved (do not install) RTCK - 1 & 2
Reserved (do not install) DBGEN - 1 & 2
** Jumper initially installed at factory.
Personality Board
0 - 6 Beater Motor Amperage
(do not use)
A
0 - 12 Beater Motor Amperage B**
** Jumper initially installed at factory.
Notes:
1. Left and right are determined while facing the
front of machine.
2. Specified feature is established when the
jumper is installed.
3. International mode (jumper removed) enables
direct use of Heat and Standby keys and
hopper temperature display.
4. Jumper should be installed on shake machines
to enable proximity sensor. It is not active on
soft serve units; jumper can remain installed.
