Taylor C723 Service Manual

56
Parts
Model C723
140519
Model C723 Operator Parts Identification
ITEM DESCRIPTION PART NO.
1 COVER-HOPPER 041682-BLA
2 ORIFICE 022465-100
3 O-RING-3/8 OD X .070W
(100 TO BAG)
016137
4 TUBE A.-FEED-SS-5/32 HOLE X29429-2
5 O-RING-.643 OD X .077W
(50 TO BAG)
018572
6 PANEL-REAR 069340
7 PANEL A.-SIDE RIGHT X68854
8 PANEL A.-FRONT X81843
9 SCREW-1/4-20X3/8 SLTD 011694
10 PANEL A.-SHELF (INCLUDES
ITEMS 10a -10c)
X81840
10a PANEL A.-FRONT-LOWER X81841
10b SHELF-DRIP TRAY 080782
ITEM DESCRIPTION PART NO.
10c SCREW-1/4-20X3/8 SLTD 011694
11 SCREW-WING HEAD 081582
12 TRAY-DRIP 080781
13 SHIELD-SPLASH-WIRE 046177-SP
14 PAN A.-DRIP 15 1/8 LONG X51601
15 STUD-NOSE CONE 055987
16 PANEL-SIDE LEFT 068851
17 FILTER ASSEMBLY X81440
17a FILTER-AIR-18.28X15.5X.70 052779-15
18 COVER-ACCESS-FRONT-R. 068844
19 SCREW-10X3/8 SLOTTED HEX 015582
20 COVER-ACCESS-LEFT 081834
21
TRIM-REAR CORNER-R 068847
TRIM-REAR CORNER-L 080238
OPTIONAL FEATURE: SOME UNITS ARE
FACTORY-EQUIPPED WITH AGITATORS.
(NOT SHOWN)

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
