Taylor C723 Service Manual

+ Available Separately
74
Parts List Model C723
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
CONTROL-INTERFCE-HT-SS-UK ROHS 063964-SER 2 212 LOWER CONTROL-REPLACES X63964-SER
CONTROL-ROHS-HT INTF BASE-UK 063920-SER 2 212 REPLACES X63920-SER PCB & X40799-SER CHIP
PCB A.-ROHS-PERSONALITY-HT-SS 063922-SER 2 212
PCB A.-INTERFACE*C712-C717*ROHS X63925-SER * 212 DEC PLATE - SEE 063925-SER CONTROL
+CABLE-RIBBON-14C-3"L-SIL/SIL 056864 1 212
PIN-RETAINING-HOPPER COVER 043934 4 103
PLATE-DEC *C723* 068830 1 103
PROBE A.-MIX X56912 2 103 MIX LOW
PROBE-MIX OUT *C708* 056908 2 000 MIX OUT
+SPACER-PROBE-MIX-MIDDLE *C70 056907 2 000
+SPACER-PROBE-MIX-UPPER *C708 056910 2 000
+SPACER-MIX PROBE *C708* 056985 2 000
+SCREW-10-32X2-1/4 SLOT. ROUND 057610 2 000
+O-RING-1-3/8 OD X .070W 017395 6 000
+NUT-10-32 HEX MACHINE SCREW 005598 4 000
+NUT-1/4-20 FINISHED HEX NUT 000707 4 000
PROBE-THERMISTOR-BARREL-2% TOL 038061-BLK * 103 N/A USE X82397-SER KIT A.-PROBE
PULLEY-2AK20 X 5/8 BORE 034238 2 103
PULLEY-2AK64-5/8 BORE 039695 2 103
RELAY-3 POLE-20A-208/240 50/60 066795-33 1 103 UPPER CONTROL
RELAY-DPDT 100UA TO 7A 1/8HP 052111-03 2 103 UPPER CONTROL
RING A.-AIR FLOW-COND.*C708* X57006 1 103
SANITIZER-STERA SHEEN -GREEN 055492 1 000
SCREW-8X1/2 SLTD HEX WASH 075763 12 000
SCREW-WING HEAD-FAST LEAD 081582 2 000
SHAFT-BEATER 054194 2 103
+SEAL-DRIVE SHAFT 032560 2 000
SHELF-DRIP TRAY *C722* 080782 1 103 S/N M2086696 & UP
+SCREW-1/4-20X3/8 SLTD ROUND 011694 2 000
SHELF-DRIP TRAY *C723* 068863 * 103 S/N M2086695 & PRIOR
SHELL A.-INSULATED *C723* X81793-SER 1 512 S/N M3044207 & UP - REPLACES X68948-SER
BEARING-REAR SHELL-NICKEL 031324 2 000

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
