Parts List Models QS11 & 23
061004
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
QS23
QTY.
QS11
QTY.
PART
NUMBER
COVER-TOP QS12/QS24 079969 1 1 103 COVER FOR GREASE TRAY DECAL-TERMINAL BLOCK *QS12* 079533 1 2 000 DECAL-TERMINAL BLOCK *QS24 079046-23L 1 000 DECAL-TERMINAL BLOCK *QS24 079046-23R 1 000 DIAGRAM-WIRING *QS11* 074626-23 1 1 000 208V 60HZ 3PH - 208V 60HZ 1PH DIAGRAM-WIRING *QS11* 074626-75 1 1 000 400V 50HZ 3N~ (4 WIRE) GASKET-GREASE CHUTE *QS24* 078663 1 103 GASKET-PARTITION*QS12/QS24* 074154 1 1 000 HANDLE A. *QS11* X74628 1 2 103 HARNESS-CONTROL TO REMOTE QS 074605 1 2 103 CONTROL TO REMOTE HARNESS-LOWER POWER *QS11* 074609 1 2 103 208V 60HZ 3PH - 240V 60HZ 3PH - 220V
50/60HZ 3PH
HARNESS-POWER LOWER *QS11* HV 074953 1 2 103 400V 50HZ 3N~ (4 WIRE) HARNESS-T/C UPPER #4 *QS11* 074602-4 1 2 103 UPPER PLATEN (FRONT) HARNESS-T/C UPPER #5 *QS11* 074602-5 1 2 103 UPPER PLATEN (MIDDLE) HARNESS-T/C UPPER #6 *QS11* 074602-6 1 2 103 UPPER PLATEN (REAR) HARNESS-UPPER POWER *QS11* 074611 1 2 103 UPPER PLATEN HEATER-CAST 208V 1800W *QS24* 079639-22 3 6 103 208V 60HZ 3PH HEATER-CAST 240V 1800W *QS24* 079639-24 3 6 103 240V 60HZ 3PH HEATER-CAST 230V 1800W *QS24* 079639-26 3 6 103 HARNESS-POWER LOWER *QS11* HV HOOD-CART *QS11* 074555 1 103 KIT A.-REAR COVER STOP BAR LH X79900 1 103
BAR-REAR-COVER SUPPORT 079855 2 103 BAR-STOP *QS12* 079673 1 103 COVER A.-REAR *QS24* L.H. X74330 1 103 COVER-HOOD STOP *QS24* 074327 1 103 GUARD A.-FRONT *QS12*QS24* X79426-SP 1 103 SCREW-10-32X3/8 TRUSS HD-SS 024298 10 000 SCREW-3/8-16X1/2 HEX CAP-ZP 001081 2 000 SLEEVE-STOP BAR *QS12* 079688 2 103
**Check Electrical Specs and for Flat or Grooved Surface.
