Taylor QS11 User Manual

Section 9 Parts List
33
+ Available Separately
Models QS11 & 23 Parts List
051108
DESCRIPTION PART
NUMBER
QS11
QTY.
QS23
QTY.
WARR. CLASS
REMARKS PARTS
UPDATE
BAR-ADJUSTING GAP *QS24* 078779 1 2 103 UPPER PLATEN BAR-GAP-ADJ SLIDE MTG *QS24* 078783 2 4 103 UPPER PLATEN BAR-RELEASE SHEET *QS24* 079930 2 4 103 BLOCK-CONTACT 1 NO *11/12/15 076013 1 103 BLOCK-GAGE PLATEN KIT .375”T 079912 4 4 103 BLOCK-TERMINAL 5P SCREW 75 A 079833 1 1 103 BLOCK-TERMINAL 6P SCREW #8 076943 1 2 103 208V 60HZ 3PH - 208V 60HZ 1PH BLOCK-TERMINAL-PLUG 6P .2 SI 040322-002 1 2 103 BLOCK-TERMINAL 7P GREEN 024156 1 1 103 400V 50HZ 3N~ (4 WIRE) BOX A.-REMOTE KEY PAD *QS11* X74612 1 2 212
BEEPER-WITH WIRE HARNESS *QS 078617 1 2 103 DECAL A.-KEYPAD QS SERIES X74320-SER 1 2 000 HARNESS-KEYPAD TIMER BUTTON 074613 1 2 103 HARNESS-WIRE REMOTE *QS24* 078614 1 2 103 PAD A.-KEY REMOTE *RETROFIT* X74618 1 2 103 PCB A.-REMOTE GRILL-GREEN X50412-SER 1 2 212
SWITCH-MEMBRANE-5 POSITION-8 044520 1 2 103
BRUSH-.625 X 1.500 *QS12/24* 074166 1 1 000 BUTTON-OPERATOR-RED 'TIMER' 074598 1 2 103 CASTER-5” RIGID 074592 2 2 103 CASTER-5” SWIVEL&POSILOC BRAKE 074593 2 2 103 CLEANER-SIZZLE KAY 545 1 CASE 079896 1 1 000 COLLAR-HOLDING 019481 4 4 103 CONTROL-HI-LIMIT 550F NO RESET 074165 3 6 103 400V 50HZ 3N~ (4 WIRE) CORD A.-POWER-4 WIRE *QS11* X74597 1 103 CORD-10-4 SO 600V *QS12* 042147-24 2 103 COVER A.-PLATEN *QS24* X78776 1 2 103 UPPER PLATEN COVER-TOP QS11 074588 1 1 103 **Check Electrical Specs and for Flat or Grooved Surface.
