Taylor QS11 User Manual

37
+ Available Separately
Models QS11 & 23 Parts List
051108
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
QS23
QTY.
QS11
QTY.
PART
NUMBER
RETAINER-BEARING *QS24* 079191 2 2 103 ROD-CYL MTG *QS24* 079195 1 1 103 ROD-LINKAGE 3/4 DIA *QS24* 079216 1 1 103 ROD-PLATEN LINKAGE MID *QS24 078549 1 1 103 ROD-PLATEN LINKAGE MID *QS24 079194 1 1 103 ROD-PLATEN LINKAGE UPPER *QS 078550 1 1 103 SCREW-1/4-20X3/8 ALLENHD-SET 039536 4 4 000
PLATE-COVER-BUTTON *QS11* 074558 1 2 103 PLATEN A.-SERV.GROOVE*QS11/23* X70965-23 ** ** 212 208V 60HZ 3PH PLATEN A.-SERV.GROOVE*QS11/23* X70965-28 ** ** 212 240V 60HZ 3PH PLATEN A.-SERV.GROOVE*QS11/23* X70965-75 ** ** 212 400V 50HZ 3N~ (4 WIRE) PLATEN A.-SERV. FLAT *QS11/23* X70966-23 ** ** 212 208V 60HZ 3PH PLATEN A.-SERV. FLAT *QS11/23* X70966-28 ** ** 212 240V 60HZ 3PH PLATEN A.-SERV. FLAT *QS11/23* X70966-75 ** ** 212 400V 50HZ 3N~ (4 WIRE) POINTER-GAP ADJ. *QS24* 078637 1 2 103 UPPER PLATEN RELAY 30A-277V-12VDC 074041 6 12 103 RELAY 24A 230V-200/240VAC 074372-26 1 1 103 400V 50HZ 3N~ (4 WIRE) RETAINER-GAP SLIDE *QS12/QS2 078792 2 4 103 UPPER PLATEN ROD-THREADED 5/16-18X1LONG 078639 1 2 103 UPPER PLATEN SCRAPER A.-GROOVE *QS12*RUBBER X79246 ** ** 103 SCRAPER A.-GROOVE *QS24*METAL X79668 ** ** 103 SCRAPER-TEFLON WIPER 075887 1 1 000 SCRAPER-TROUGH *QS24* 079726 1 1 000 SHEET-SEAMED RELEASE *QS24* 078804 2 4 000 SHIELD-GREASE FRONT *QS24* 079433 1 1 103 SHIELD-GREASE REAR *QS24* 079434 1 1 103 SHIELD-HEAT/GREASE-CART *QS11* 074585 1 2 103 SLIDE A.-GAP FRONT *QS24* X78864-F 1 2 103 UPPER PLATEN SLIDE A.-GAP REAR *QS24* X78864-R 1 2 103 UPPER PLATEN **Check Electrical Specs and for Flat or Grooved Surface.
