Models BC10/BW1 1 Operator Parts Identification
130524
BC10 Standard Unit - Exploded View Parts Identificatio n
ITEM DESCRIPTION PART NO.
1 CAP - MIXER 051484
2 SCREW- MIXER- RETAINER
CAP
051487
3
BREAKER- CIRCUIT- MIXER -
3A- 120V
051489
BREAKER- CIRCUIT- MIXER - 5A
- 220/240V
051490
4 CORD- MIXER- 18/3
GROUNDED W/PLUG
051491
5 FOOT A. - MIXER- PLUGGED-
PKG OF 4
051500
6 GUARD - SPLASH- MIXER 051499
7 PIVOT PIN&SCREW*PKG OF 4* 051507
8 AGITATOR- MIXER- PERM SOFT 051497
9 SHAFT - MIXER- AGITATOR- EXT
- PERMANENT
051495
ITEM DESCRIPTION PART NO.
10 SLINGER- MIXER 051494
11 SWITCH- ROCKER- MIXER 051488
12 LABEL - MIXER- COUNTER-
RAZZLE
052250
13
PEDAL - FOOT- MIXER - 120V 052451
PEDAL - FOOT- MIXER - 220V 053192
13a TRANSMITTER FOOT PEDAL 052451- 1
13b
CONTROLLER- FOOT PEDAL-
115V
052451- 2
SWITCH- PRESSURE- FOOT
PEDAL - 220
053192- 1
13c TUBE - AIR - FOOT PEDAL 052451- 3
