19
Models BC10/BW1 1 Operator Parts Identification
Optional Small Candy Dispenser Canister Assembly (X53638- 2)
ITEM DESCRIPTION PART NO.
2 CANISTER A.- SM. CANDY DISP. (2) X53638- 2
2a COVER - CANDY DISPENSER- SMALL 052032- 2
2b SHAFT A.- SHORT W/AGITATORS X53530- 2
2c PLATE- ANTI- ROTATION INS. W/POST 053581
ITEM DESCRIPTION PART NO.
2d PUCK A.- CANDY DISPENSER X52027
2e CANISTER- CANDY DISPENSER- SM. 052033- 2
2f KNOB A.- CANDY DISPENSER X51564
