18
Models BC10/BW1 1Operator Parts Identification
Optional Large Candy Dispenser Canister Assembly (X53638- 1)
ITEM DESCRIPTION PART NO.
1 CANISTER A. - LARGE CANDY DISP. X53638- 1
1a COVER - CANDY DISPENSER- LARGE 052032- 1
1b SHAFT A.- LONG W/AGITATORS X53530- 1
1c PLATE- ANTI- ROTATION INS. W/POST 053581
ITEM DESCRIPTION PART NO.
1d PUCK A.- CANDY DISPENSER X52027
1e CANISTER- CANDY DISPENSER- LG. 052033- 1
1f KNOB A.- CANDY DISPENSER X51564
To Next Page
