Models BC10/BW11 Important: To the Operator
Splash Guard
The splash guard functions as a built- in cup limiter
which protects the cups from agitator penetration. The
splash guard also helps keep the inside of the housing
clean.
The splash guard for the Model BC10 (counter- top)
slides up and down on stainless steel rods. The splash
guard for the Model BW11 (wall mount) rotates upward
for easy operation.
Figure 4
Motor
The motor features a heavy duty, ball bearing induction
motor and does not use brushes, belts, couplings, or
gears. This design reduces power consumption, heat,
noise, and wear. The motor maintains an optimal
speed of 3,485 RPM to maintain product consistency.
Agitators
Permanent Agitator
Material: NSF accepted Acetal
The non- metal permanent agitator can be carefully
pushed up against the inside of the paper or plastic
cups with no damage to the cup.
IMPORTANT: The shaft must be cleaned between
servings as product carryover will occur.
(See page 26 for cleaning instructions.)
Figure 5
Removable Spoon Agitator
Material: NSF accepted Eastman Tritant
The non- metal single serve agitator/spoon clips onto
the machine for mixing and removal for use as a
serving spoon. The spoon agitator increases the
speed of service and prevents flavors, colorings, and
potential allergens from being transferred from serving
to serving, while not damaging paper or plastic cups
during processing.
Figure 6
