TBB Projecta PMDC-30 - PMDC-30 Specifications

10
6. SPECIFICATION
Model Number PMDC-30
Electrical
Alternator input voltage range (Intelligent type) 12~16VDC
Automatic activation D+ Yes
Absorption charge voltage Default Setting: 14.8VDC
Float charge voltage Default Setting: 13.8VDC
Charge current 30A
Total current of load and charging 30A
Maximum charging efficiency 96%
Temperature compensation Default Setting: -3mV/°C/cell
Voltage compensation Yes
Charge algorithm Premium II multi stage
Protection • Battery charger over temperature
• Over load
• Short circuit
Communication RS485, RJ45 connector
Storage temperature -40°C ~70°C
Operating temperature -40°C ~70°C
Enclosure
Battery Connection Cable with connector
Protection category IP20
Weight 1.0kg
Dimensions (h*w*d) 181*148*52mm
Standards
Emission ECE 10R-06, EN61000-6-1, EN61000-6-3
