TBS PDB V2 with integrated DCDC - Power distribution and power supply layer (NEW!)
Power distribution:
100A max. continuous current, 150A burst
Current sensor:
100A, 0.1A resolution, 2% accuracy, BST-compatible (e.g for TBS CORE PRO)
Inputs:
• 1x Battery V+ and GND, 150A max
• 1x Internal BUS system (6x PWM, BST, 5V, 12V)
Ports:
• CAM - FPV camera port, 5V/12V selectable on PCB (factory set to 12V)
• VTX - FPV video transmitter port, 5V/12V/VBat selectable on PCB (factory
set to 5V)
• BST - BlackSheep Telemetry port, connects to TBS CORE PRO OSD
Power supply:
5V @ 4A NEW!, 12V @ 0.2A, combined max. draw
Connectors:
Molex Picoblade 1.25mm, 4-pin for VTX and CAM, 5-pin for BST
TBS POWERCUBE - Stack details
Working temperature:
0°C to 85°C
Dimensions:
36 x 36 x 30mm (with 4 ESCs)
Weight:
70g - brass standoff version
62g - aluminum-gold standoff version (available in PRO tuning kit)
Basic kit contents:
• 1x TBS COLIBRI V2.0 flight control NEW!
• 4x TBS BULLETPROOF speed control w/2mm female bullet connector
• 1x TBS PDB V2 w/ XT60 connector NEW!
• 1x Plastic isolation layer
• 1x PPM/SBUS cable
• 1x Spektrum cable
• 1x Piezo buzzer
• 1x LED pigtail
TBS FPVision OSD/VTX - CORE PRO OSD, Video Transmitter, Power Distribution and Power Supply
Power distribution:
100A max. continuous current, 150A burst
Current sensor:
100A, 0.1A resolution, 2% accuracy
Inputs:
• 1x Battery V+ and GND, 150A max.
• 1x Internal BUS system (6x PWM, BST, 5V, 12V)
• 1x VTX menu button
Ports:
• 2x CAM - FPV cam port, 5V/12V selectable via TBS Agent (5V default)
• 1x BST - BlackSheep Telemetry port, connects to TBS ecosystem
• 1x U.FL SMD VTX antenna connector
Power supply:
5V @ 4A, 12V @ 0.2A, combined max. draw
Connectors:
Molex Picoblade 1.25mm, 4-pin for CAM inputs, 5-pin for BST
