TC Electronic Flashback Triple Delay User Manual

Technical specifications
Flashback Triple Delay English manual 2014-10-14 35
Please note that due to continuous development, the following specifications are subject to change without further notice.
Bypass mode True Bypass (Buffered Bypass optional)
Signal circuitry Analog dry-through
Dimensions (width x depth x height) 235 x 145 x 57mm
Input connector 2 Standard ¼” jacks – mono/TS with automatic mono/stereo sensing
Input impedance 1MΩ
Output connector 2 Standard ¼” jacks – mono/TS with automatic mono/stereo sensing
Output impedance 100Ω
Expression pedal connector Standard ¼” jack
Power input Standard 9V DC, centre negative >300mA (power supply included)
MIDI IN + MIDI THRU Standard 5 Pin DIN connectors
USB port Mini USB connector for uploading and editing custom TonePrints and for software updates

TC Electronic Flashback Triple Delay Specifications

General

Product type	Pedal
Product color	Blue
Built-in display	No
Manual	Yes

Weight and Dimensions

Depth	145 mm
Width	235 mm
Height	57 mm
