TC Electronic Flashback X4 Delay User Manual

Technical specifications
Flashback X4 Delay – Manual (2014-06-24) 38
Please note that due to continuous development, the following specifications are subject to change without further notice.
Bypass mode True Bypass (Buffered Bypass optional)
Signal circuitry Analog dry-through
Dimensions (width x depth x height) 235 x 145 x 57mm
Input connector 2 Standard ¼” jacks – mono/TS with automatic mono/stereo sensing
Input impedance 1MΩ
Output connector 2 Standard ¼” jacks – mono/TS with automatic mono/stereo sensing
Output impedance 100Ω
Expression pedal connector Standard ¼” jack
Power input Standard 9V DC, centre negative >300mA (power supply included)
MIDI IN + MIDI THRU Standard 5 Pin DIN connectors
USB port Mini USB connector for uploading and editing custom TonePrints and for software updates

TC Electronic Flashback X4 Delay Specifications

General

Brand	TC Electronic
Model	Flashback X4 Delay
Category	Recording Equipment
Language	English
