14
1. Input Knob
Controls the microphone pre-amplifier gain. Correct can
accept dynamic or condenser microphones.
2. Input Light
Indicates the input level of the microphone. Flashing
green, sometimes orange is good. Flashing red is clipping,
which is not good.
3. Shape Knob
Controls the amount of Shape EQ on the voice. 12
o’clock is the default position, full left is off.
4. Compress Knob
Controls the amount of compression on the voice. 12
o’clock is the default position, full left is off.
5. De-ess Knob
Controls the amount of de-essing on the voice. 12
o’clock is the default position, full left is off.
Front & Back Panel Descriptions
1 2 3 4 5
6
8
7
10
13
14
11
9
12
