TCF IM-995 - Overview of Centrifugal Fan Arrangements

IM-995
Installation, Operation & Maintenance Manual
2
Centrifugal Fan Arrangements - Single Width, Single Inlet (SWSI)
Arrangement 4S


Arrangement 8

Arrangement 7SI

Arrangement 4VI


Arrangement 7

Arrangement 4HI


Arrangement 10

Arrangement 9

Arrangement 9F

Arrangement 9SS


Arrangement 1

Arrangement 3

Arrangement 3F

Arrangement 3SI

Arrangement 4

Arrangement 9H

Arrangement 9ST


Centrifugal Fan Arrangements - Double Width, Double Inlet (DWDI)
Arrangement 3

Arrangement 3F

Arrangement 3DI

Arrangement 7

Arrangement 7DI

