Colour Television Chassis: M123A
50
7.11 Faultfinding and Test point with Waveform Diagram
Wave Shape
NO .
Wave Shape
Freq.
Vpp
Period
Hz
WF 1
15.74
kHz
64
us
2.77
V
WF 3
15.74
kHz
64
us
925
V
WF 2
15.74
kHz
64
us
10.88
V
WF 4
WF 5
WF 6
60
KHz
16.7
ms
135.7
mV
60
KHz
16.7
ms
2.95
V
60
KHz
16.7
ms
4.94
V
