Item No. Description Quantity Designator Remarks
06-0F3046-B004X 1
11-0BC337-0BX TRANSISTOR (NPN) BC337-40 1 Q1501
13-00AS12-13B IC AS1213B 1 IC1501
14-IRE05B-XX0 IR EMITTING DIODE TSAL6200 1 D1501
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R1503
18-CB0229-JNX RES. C.F. 2.2 OHM 1/6W +/-5% 1 R1501
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C1504
26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C1501
26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C1502
26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C1503
40-UOCASF-RMA P.C.B. REMOTE HANDSET BD 1
45-COS455-KY0 CERAMIC RESONATOR 455KHZ 1 X1501
49-HS46F0-00X1C RUBBER PAD KEYS 1
55-HS46FB-0HA5B BOTTOM CASE 1
55-HS46FD-0HA5B BATTERY DOOR 1
55-HS46FT-0HA1B CASE UPPER - REMOTE HANDSET 1
63-B26060-BT2 S/T SCREW B 2.6 X 6 BT 1
67-X26968-0E2 BATT. TERMINAL (+/-) 1
67-X31028-0E2 SPRING - BATTERY (-) 1
67-X31029-0E2 SPRING - BATTERY (+) 1
58-HS46F3-JUI1A INLAY REMOTE HANDSET 1
08-2170SG-FCN ASS'Y- FRONT CABINET 1
02-GND021-XX0 ASS"Y - CRT GND WIRE&HOUSE 1 FOR CRT GROUNDING
36-DEG210-BX1 DEGAUSSING COIL 2500mm 1
42-61308E-XX0 SPEAKER (58MMX128MM) 8 OHM 6W 1 W601
42-61308E-XX0 SPEAKER (58MMX128MM) 8 OHM 6W 1 W602
46-14026H-02X HS 2P 2468#22 570mm S11-2Y/7mm 1 P601H FOR M. BD P601
46-27688H-04X HS 4P A/B 400/13 RBGW TJC1/4Y 1 P401H FOR D.Y COIL
46-35196H-02X HS 2P22 570/7 TJC3-2Y 1 P602H FOR M. BD P602
54-113970-0U0 PVC TUBE #5 L=ROLL 0.32 FOR SPK HOUSING
54-205140-000 SPACER CRT MOUNTING T=2MM 4 FOR CRT
54-314740-0X0 CRT FIBRE SHEET (22mmX22mmX0.8mm) 4
56-2170FB-0HA5B PUSH BUTTON 1
56-2170LE-0HCAA LENS 1
56-2170PK-0HA5B POWER KNOB 1
56-2170SL-1HN5B SPRAKER GRILLE (LEFT) 1
56-2170SR-1HN5B SPEAKER GRILLE (RIGHT) 1
59-130460-00X RUBBER PAD (25mmX7mm) 2 FOR FRONT CAB. & CRT
Colour Television Chassis: M123A
69
12. Part List
