TCL CTR1042 User Manual

Item No. Description Quantity Designator Remarks
59-130460-00X RUBBER PAD (25mmX7mm) 2 FOR FRONT CAB.(FOOTING)
59-312160-000 SPEAKER RUBBER CUSHION 8 MTG SPK
62-216340-0UA HOLDER POWER CORD HIPS-KINGFA 113(VO) 1
62-377180-0HA CONECTOR 1
63-B40150-AB4 S/T SCREW B 4 X 15 AB 20 MTG CRT BKT & FRONT CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 1 MTG LENS & FRONT CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 3 MTG PUSH BUTTON & FRONT CAB.
63-W30140-HS4 S/T SCREW W 3 X 14 HS 8 FOR SPK & FRONT CAB.
65-A60180-20E EXT. TOOTH WASHTER 6 X 18 X 2 4 FOR CRT
65-Z60100-50E NUT M 6 4 FOR CRT
67-325570-2E0 CRT BRACKET 4 MTG F.CAB & CRT
67-X12668-0E0 SPRING CRT 6mmX40mmX0.5mm 1
67-X25045-0E0 SPRING KNOB 1
62-345690-1UN ASSISTANT RAIL HIPS-KINGFA 113 (VO) 1
63-W30100-AB4 S/T SCREW W 3 X 10 AB 2 ••••••••••••
57-10654X-00F
cable ties(2.5mmX95mm) 6
57-396790-0HG LINE NIP 1
55-2170FC-3UA1K FRONT CABINET 1
58-2970SI-3UI INLAY SIDE AV 1
44-21RFLN-SZ3A CRT A51QDX993X002(H) 1 CRT01
08-2170SG-MAN ASS'Y- MAIN BD 1
07-457FF5-NX7 ALPS FS TUNER TEDH9-249A 1 TU101
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D402
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D401
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D403
10-1N4001-EBX DIODE 1N4001 (RECTIFIER) 1 D301
10-1N4002-EBX DIODE 1N4002 (RECTIFIER) 1 D405
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D005
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D206
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D006
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D007
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D601
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D008
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D602
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D009
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D307
10-79C33V-DBX DIODE ZENER 33V 1/2W 5% 1 D101
10-79C5V1-DBX DIODE ZENER 5V1 1/2W 5% 1 D001
Colour Television Chassis: M123A
70
12. Part List
