TCL Air Conditioner Service Manual
24
7
Separate the connectors of the
display PCB
8
Unscrew 3 screws of electrical box
cover
9
Remove the electrical box cover
10
Capacitor of condenser fan motor
（left)
Capacitor of evaporator fan motor
（right)
11
Unscrew 1 screw，then take out
compressor capacitor
12
Support bar
