TCL Air Conditioner Service Manual
40
Outdoor Unit- TAC-07CS/K, TAC-09CS/K
No. Part No. Part Name Q’ty Remark
1 1083510901 Grille 1
Optional
2 1080050016 Top Cover 1
3 1210250112 Condenser 1
4 1080050015 Outdoor Motor Supporter 1
5 1170040062 Outdoor Motor 1
6 1070030006 Propeller Fan 1
7 1080050012 Left Plate 1
8 1080050018 Front Plate 1
9 1080050019 Fan Guard 1
10 1210250101 Capillary Assembly 1
11 --------------- Compressor and its Accessories 1
12 1120250608 Discharge Pipe 1
13 1123521402 Suction Pipe 1
14 1213530414 Base 1
15 1120120008 Two-way Valve 1
16 1080050014 Valve Supporter 1
17 1120130011 Three-way Valve 1
18 1080050013 Right Plate 1
19 1073521301 Electrical Box Cover 1
20 1080020001 Electrical Parts Box 1
21 1080010002 Capacitor Strip 1
22 1170100014 Compressor Capacitor 1
23 1170100031 Fan Motor Capacitor 1
24 1170200019 Terminal 1
25 1070040002 Cable Clamp(φ7) 1
26 1173570501 Compressor Power Supply
Wiring
1
27 1173570502 Earthing Wiring 1
28 1190070014 Base Carton 1
29 1190250201 Cabinet Carton 1
30 1190070016 Base Foaming 1
31 1190070015 Cover Forming 1
Not shown in the Explosion
view.
To Next Page
